RAM 3500 | 2.5 PERFORMANCE SERIES

Brand: FOX
SKU: 987-24-051
Kit Component List

×

List Price

$329.95

Your Price

$329.95

In Stock

Subtotal: $329.95

Save to Build List

Find a Local Installer
https://serenity-foxfactory.asset.akeneo.cloud/fox_asset_family/media/987_24_009_P04.png

RAM 3500 | 2.5 PERFORMANCE SERIES

$329.95
https://serenity-foxfactory.asset.akeneo.cloud/fox_asset_family/media/987_24_009_P04.png
https://serenity-foxfactory.asset.akeneo.cloud/fox_asset_family/media/987_24_009_P01.png
https://serenity-foxfactory.asset.akeneo.cloud/fox_asset_family/media/987_24_009_P07.png
https://serenity-foxfactory.asset.akeneo.cloud/fox_asset_family/media/987_24_002_P_05.png

RAM 3500 | 2.5 PERFORMANCE SERIES

$329.95
OVERVIEW

FOX 2.5 Performance Series HTO shock is a bolt-on shock loaded with position-sensitive technology vehicle-specific valving and larger pistons to improve on and off-road performance. A type II anodized aluminum body efficiently dissipates heat and prevents corrosion. The 2.5-inch shock body features an internal floating piston (IFP) to separate the shock oil from the high-pressure nitrogen optimizing damping. Hydraulic Top Out (HTO) technology offers usable position-sensitive rebound damping control on and off the pavement. HTO reduces harsh top-outs and increases comfort by forcing shock oil through a secondary shim stack to slow down shock shaft speed; HTO is particularly beneficial after installing heavier aggressive tires and applications lifted higher than OEM specification. Bolt-on 2.5 Performance Series HTO shocks to increase damping capacity and ride in comfort with position-sensitive rebound control.

IMPORTANT NOTES
INSTALLATION
SPECIFICATION
  • Rear Lift Height : 4-6"
  • Compressed Length : 20.25
  • Extended Length : 32.89
  • Position : Rear
  • Travel Length : 12.64
FITMENT
2025|Ram|3500|*|4WD|*|*|7556|Shock Absorber|EA|2|||W/ Single Rear Wheels, Does not fit Air Suspension Equipped Trucks|Rear|30|4"-6"||||||||||;2018|Ram|3500|*|4WD|*|*|7556|Shock Absorber|EA|2|||W/ Single Rear Wheels, Does not fit Air Suspension Equipped Trucks|Rear|30|4"-6"||||||||||;2026|Ram|3500|*|4WD|*|*|7556|Shock Absorber|EA|2|||W/ Single Rear Wheels, Does not fit Air Suspension Equipped Trucks|Rear|30|4"-6"||||||||||;2020|Ram|3500|*|4WD|*|*|7556|Shock Absorber|EA|2|||W/ Single Rear Wheels, Does not fit Air Suspension Equipped Trucks|Rear|30|4"-6"||||||||||;2023|Ram|3500|*|4WD|*|*|7556|Shock Absorber|EA|2|||W/ Single Rear Wheels, Does not fit Air Suspension Equipped Trucks|Rear|30|4"-6"||||||||||;2016|Ram|3500|*|4WD|*|*|7556|Shock Absorber|EA|2|||W/ Single Rear Wheels, Does not fit Air Suspension Equipped Trucks|Rear|30|4"-6"||||||||||;2017|Ram|3500|*|4WD|*|*|7556|Shock Absorber|EA|2|||W/ Single Rear Wheels, Does not fit Air Suspension Equipped Trucks|Rear|30|4"-6"||||||||||;2022|Ram|3500|*|4WD|*|*|7556|Shock Absorber|EA|2|||W/ Single Rear Wheels, Does not fit Air Suspension Equipped Trucks|Rear|30|4"-6"||||||||||;2024|Ram|3500|*|4WD|*|*|7556|Shock Absorber|EA|2|||W/ Single Rear Wheels, Does not fit Air Suspension Equipped Trucks|Rear|30|4"-6"||||||||||;2021|Ram|3500|*|4WD|*|*|7556|Shock Absorber|EA|2|||W/ Single Rear Wheels, Does not fit Air Suspension Equipped Trucks|Rear|30|4"-6"||||||||||;2014|Ram|3500|*|4WD|*|*|7556|Shock Absorber|EA|2|||W/ Single Rear Wheels, Does not fit Air Suspension Equipped Trucks|Rear|30|4"-6"||||||||||;2019|Ram|3500|*|4WD|*|*|7556|Shock Absorber|EA|2|||W/ Single Rear Wheels, Does not fit Air Suspension Equipped Trucks|Rear|30|4"-6"||||||||||;2015|Ram|3500|*|4WD|*|*|7556|Shock Absorber|EA|2|||W/ Single Rear Wheels, Does not fit Air Suspension Equipped Trucks|Rear|30|4"-6"||||||||||
